The wire diameter range of this welded mesh machine is 3-8mm, and the mesh width is 2000mm, 2500mm, and 3000mm. The finished product can be sheet or coil. The welding current and time of each welding transformer can be adjusted individually. Automatically realize continuous feeding, straightening, cutting, welding and laying of longitudinal wires of coils. The net pulling system adopts servo motor control, which not only improves. The accuracy of the mesh size also ensures the adjustability of the distance between the longitudinal and cross wires.
Product Advantages
Improved safety: The automated operation of the mesh welding machine reduces the risk of manual operation and improves construction safety.
The mesh-drawing mechanism uses a servo motor to drive a pneumatic clamping mesh-drawing device to make the mesh size more precise and standard; continuous reciprocating mesh-drawing can realize the production of mesh sheets of different sizes.
The machine has a long service life, and the upper and lower welding copper blocks and other parts have low wear rate.
Product Usage
3-8mm steel mesh welding machine is widely used in construction, agriculture, breeding and other fields.It can be used in the production and manufacturing of coal mine support nets, guardrail nets, high-rise building steel bridge nets, highway steel bar nets, construction steel bar nets, floor cast roof nets, etc.
Technique Parameter
| Model | GWJ2000 | GWJ2500 | GWJ3000 |
| Max Mesh width | 2000mm | 2500mm | 3000mm |
| Mesh Length | 3-8m(Max12m) | 3-8m(Max12m） | 3-8m(Max12m） |
| Mesh type | By sheet or coil | By sheet or coil | By sheet or coil |
| Line Wire Spacing | 100-300mm | 100-300mm | 100-300mm |
| CrossWire Spacing | 50-300mm | 50-300mm | 50-300mm |
| Wire Diameter | 3-12mm | 3-12mm | 3-12mm |
| Line Wire Type | by coils | by coils | by coils |
| Cross Wire Type | Bars | Bars | Bars |
| Welding speed | 60-85times/min | 60-85times/min | 60-85times/min |
| Electric Power | 185KVAX5 | 185KVAX6 | 185KVAX8 |
01
Requirement Communication
We discussed the detaills for customer’s requirements including product specifications, functions, etc.
02
Scheme Design
According to customer needs, the company's design department provides a preliminary design plan and confirms it with the customer.
03
Technical Evaluation
The technical team conducts a feasibility evaluation of the plan to ensure that it meets production requirements and customer needs.
04
Contract Signing
After the two parties reach a consensus on the design plan, price, delivery date, etc., they sign a formal contract.
05
Manufacturing
The production department customizes the equipment according to the contract requirements to ensure quality and performance.
06
Quality Inspection
The quality inspection department conducts strict debugging and inspection of the finished equipment to ensure that it meets customer requirements.
07
Delivery Acceptance
After the customer's on-site/video debugging and acceptance is qualified, the product will be delivered and relevant operation guidance will be provided.
