Straight Wire Drawing Machine

Straight Wire Drawing Machine,This type of machine under finished product line has high quality, smooth surace and thickness Evenly, which take good coolingsystem, water cooling and air cooling, good quality high reliability, low shutdown. This type of machine uses PLC+ frequencyconversion speed regulation, convenient operation.Structure includes hydraulic pay-oft, hydraulic descaler, brushes descaler, main blocks, hydraulic take-up machine. Detail pat can bedesign and require by your detail need.

Inquire Now

Advantage

1. Water cooling reduces the heat generated in the drawing process and reducesMold loss, improve wire quality.

2. High quality of finished line, smooth surface, thickness uniform.

3. Tunasten carbide spray the drums. long service life

4. Hiah speed with inverter speed adiustable

Application:

Wire drawing processing for high, medium and low carbon steel wire, stainless steel wire, copper wire, alloy copper wire, aluminum alloy copper wire, etc

Machine Parameters

Type	LNSD9-900	LNSD9-800	LNSD9-700	LNSD10-600	LNSD10-400
Drum Dia./mm	900	800	700	600	400
Drawing Passes/time	9	9	9	10	10
Max.Inlet Wire Dia. mm	8-14	8-10	6.5-8	5.5-6.5	1.8-2.5
Min.Outlet Wire Dia.mm	3-5	3-4	2.5-3	1.8-2	0.75-1
Drawing Speed m/min	300	360	480	750	840
Inlet Wire Strength kg/m²	≤1300	≤1300	≤1300	≤1300	≤1300
Total Compressibility%	85.94-87.24	84-85.94	85.21-85.94	89.29-90.53	87.24
Average Compressibility%	19.58-20.48	18.42-19.58	19.13-19.58	21.00-21.02	18.61
Motor Power kW	90-110	55-90	22-37、	22-37	7.5-15
Weightkg	9500
Diamension mm	1000018001300

In addition to this, we can customize to your special specifications

Customization Process

Customize Now
01

Requirement Communication

We discussed the detaills for customer’s requirements including product specifications, functions, etc.
02

Scheme Design

According to customer needs, the company's design department provides a preliminary design plan and confirms it with the customer.
03

Technical Evaluation

The technical team conducts a feasibility evaluation of the plan to ensure that it meets production requirements and customer needs.
04

Contract Signing

After the two parties reach a consensus on the design plan, price, delivery date, etc., they sign a formal contract.
05

Manufacturing

The production department customizes the equipment according to the contract requirements to ensure quality and performance.
06

Quality Inspection

The quality inspection department conducts strict debugging and inspection of the finished equipment to ensure that it meets customer requirements.
07

Delivery Acceptance

After the customer's on-site/video debugging and acceptance is qualified, the product will be delivered and relevant operation guidance will be provided.
